Tall pantry cabinet 600 600 × 2100 × 560: cut list and cutting plan
A full-height kitchen larder: 2000 mm carcass on 100 mm legs, five adjustable shelves and one tall door. 18 mm board, 3 mm HDF back. All sizes in millimetres.
Cut list
| Part | Length × width, mm | Qty | Edge banding |
|---|---|---|---|
| Side | 2000 × 560 | 2 | 1 long |
| Top | 564 × 560 | 1 | 1 long |
| Bottom | 564 × 560 | 1 | 1 long |
| Shelf | 562 × 540 | 5 | 1 long |
| Door | 1997 × 597 | 1 | all |
Not cut from the board: Adjustable legs, 100 mm: 4 pcs; kick plinth 600 × 95 mm (cut to length) · Back panel, HDF 3 mm: 596 × 1996 mm · 4 adjustable legs, 100 mm · 5 cup hinges, 35 mm · 20 shelf pins · 1 long handle · kick plinth bought separately
How the sizes are worked out
- Sides 2000 × 560 (carcass height; the 100 mm legs bring it to 2100).
- Top and bottom = 600 − 36 = 564; shelves 562 × 540.
- One door 1997 × 597 covers the whole front with a 3 mm gap.
- A 2 m door can warp — use straight board, five hinges and keep it the same material on both faces.
Cutting plan on 2440 × 1220 sheets
Laid out by the CutRun calculator with a 3 mm saw kerf and 10 mm trimmed off the factory edges.
62 % of the board ends up in the furniture. The last sheet has a large piece left over — plan extra shelves, a drawer or a second small cabinet into the same order.
Other sizes on 2440 × 1220 sheets
Same construction, worked out by the calculator for other common sizes (width × height × depth, mm):
| Size | Sheets | Board | Edge banding |
|---|---|---|---|
| 400 × 2100 × 560 | 2 | 4.42 m² | 11.3 m |
| 500 × 2100 × 560 | 3 | 5.00 m² | 12.2 m |
| 500 × 2300 × 560 | 3 | 5.32 m² | 13.0 m |
| 600 × 2000 × 560 | 3 | 5.41 m² | 12.7 m |
| 600 × 2100 × 560 | 3 | 5.58 m² | 13.1 m |
| 600 × 2300 × 560 | 3 | 5.92 m² | 13.9 m |
400 × 2100 × 560 is the largest size in this table that still needs only 2 sheets (74 % used).
Assembly order
- Band the edges: door all round, the rest on the front edge.
- Drill shelf-pin rows, assemble the carcass lying down, nail on the back.
- Screw on the legs, stand it up, level it and fix it to the wall.
- Insert the shelves, hang the door and adjust the hinges.
Questions
How many sheets do I need for a tall pantry cabinet?
A 600 × 2100 × 560 mm version in 18 mm board needs 3 sheets of 2440 × 1220 mm: 5.58 m² of board and about 13.1 m of edge banding. The 3 mm HDF back is cut from a separate thin sheet.
How many hinges does a 2 m pantry door need?
Five hinges for a door around 2000 mm high; four is the minimum and the door may twist.
How tall is a kitchen tall cabinet?
Usually 2000–2300 mm including legs, chosen to line up with the top of the wall cabinets.
Need a different size? Open this design in the cabinet builder, type your own width, height and depth or change shelves, drawers and doors — the cut list and the drawing update as you go. Then send it to the calculator for your own sheet size.
Open in the cabinet builder How to calculate edge bandingWorked out from a typical construction — check every size against your board and hardware before you cut. Cut list and sheet layout made with CutRun.
