Shoe cabinet 900 × 1000 × 300: cut list and cutting plan
A shallow hallway cabinet for about 16 pairs of shoes: three shelves behind two doors on a 60 mm plinth. 18 mm board, 3 mm HDF back. All sizes in millimetres.
Cut list
| Part | Length × width, mm | Qty | Edge banding |
|---|---|---|---|
| Side | 1000 × 300 | 2 | 1 long |
| Top | 864 × 300 | 1 | 1 long |
| Bottom | 864 × 300 | 1 | 1 long |
| Plinth | 864 × 60 | 1 | — |
| Shelf | 862 × 280 | 3 | 1 long |
| Door | 937 × 447 | 2 | all |
Not cut from the board: Back panel, HDF 3 mm: 896 × 936 mm · 4 cup hinges, 35 mm, full overlay (2 per door) · 12 shelf pins · 2 handles · about 12 confirmat screws 7 × 50
How the sizes are worked out
- Depth 300 is enough for most shoes up to size 46 if they stand straight.
- Top, bottom, plinth = 900 − 36 = 864; shelves 862 × 280.
- Doors 937 × 447: height 1000 − 60 − 3, width (900 − 6) / 2.
- Leave a 20–30 mm gap behind the shelves or drill a row of holes in them so wet shoes can air.
Cutting plan on 2440 × 1220 sheets
Laid out by the CutRun calculator with a 3 mm saw kerf and 10 mm trimmed off the factory edges.
46 % of the board ends up in the furniture. The last sheet has a large piece left over — plan extra shelves, a drawer or a second small cabinet into the same order.
Other sizes on 2440 × 1220 sheets
Same construction, worked out by the calculator for other common sizes (width × height × depth, mm):
| Size | Sheets | Board | Edge banding |
|---|---|---|---|
| 600 × 1000 × 300 | 1 | 2.00 m² | 9.8 m |
| 800 × 1000 × 300 | 1 | 2.49 m² | 11.2 m |
| 900 × 800 × 300 | 1 | 2.43 m² | 10.7 m |
| 900 × 1000 × 300 | 2 | 2.73 m² | 11.8 m |
| 900 × 1000 × 350 | 2 | 3.05 m² | 11.8 m |
| 1000 × 1200 × 300 | 2 | 3.29 m² | 13.8 m |
| 1200 × 1000 × 300 | 2 | 3.46 m² | 13.9 m |
800 × 1000 × 300 is the largest size in this table that fits on a single sheet (84 % of it used).
Assembly order
- Band the edges: doors all round, the rest on the front edge.
- Drill shelf-pin rows in the sides so the shelf spacing can follow boots and sneakers.
- Assemble the carcass, nail on the back.
- Insert the shelves, hang the doors.
Questions
How many sheets do I need for a shoe cabinet?
A 900 × 1000 × 300 mm version in 18 mm board needs 2 sheets of 2440 × 1220 mm: 2.73 m² of board and about 11.8 m of edge banding. The 3 mm HDF back is cut from a separate thin sheet.
How deep should a shoe cabinet be?
300 mm for shoes standing straight, 350–400 mm if you want boots or large sizes to fit. Tilted shelves allow about 200 mm.
How many pairs fit?
About five to six pairs per 900 mm shelf, so 15–18 pairs on three shelves plus the bottom.
Need a different size? Open this design in the cabinet builder, type your own width, height and depth or change shelves, drawers and doors — the cut list and the drawing update as you go. Then send it to the calculator for your own sheet size.
Open in the cabinet builder How to calculate edge bandingWorked out from a typical construction — check every size against your board and hardware before you cut. Cut list and sheet layout made with CutRun.
